The GWZOOM GZFR30 F is a 3 ton forklift engineered for maximum versatility across challenging terrains. Popular as a rough terrain forklift for rent in construction and mining operations, this model combines affordability with rugged dependability. The F-Type design prioritizes cost-efficiency while maintaining the core capabilities required for outdoor material handling. Whether purchasing or considering rental, this forklift delivers consistent performance with minimal downtime, supported by GWZOOM's global parts network.
Key Technical Parameters | ||
Model | GZFR30 F | |
| Rated Load | kg | 3000 |
| Load Center Distance | mm | 500 |
| Wheelbase | mm | 1900 |
| Kingpin Height | mm | 620 |
| Minimum Ground Clearance (At the Mast) | mm | 260 |
| Track Width (Front/Rear) | mm | 1460 |
| Minimum Turning Radius (Outer) | mm | 3900 |
| Minimum Turning Radius (Inner) | mm | 2100 |
| Front Tire | 20.5/70-16 | |
| Rear Tire | 20.5/70-16 | |
| Engine | Yunnei 490 | |
| Engine Power/Speed | kw/rpm | 37/2200-2400 |
| Number of Transmission Gears | Front 2/ Rear 2 | |
